- Accurately measure gas pressure with Vernier Go Direct Gas Pressure Sensor
- Easy-to-use sensor with wireless connectivity for real-time data collection
- Compatible with multiple devices and software for seamless integration
- Durable design for use in various environments and applications
- Ideal for scientific research, classroom experiments, and industrial processes
IMPORTANT – FEDEX GROUND SHIPPING ONLY.
Product is NOT eligible for Free Shipping and other promotions.
Use Go Direct Gas Pressure Sensor to monitor gas pressure in a variety of experiments. It records accurate absolute pressure readings relative to the perfect vacuum reference point inside the sensor, allowing you to go below atmospheric pressure or up to 400 kPa. Easily change the displayed units to any one of seven options (kPa, mmHg, inHg, mbar, psi, atm, torr). Includes a syringe, tubing, and stoppers to ease setup for experiments such as Boyle’s Law.
Wirelessly connect most Go Direct sensors to the Graphical Analysis Pro app in just seconds and collect, visualize, and interact with data in real time, from anywhere and on multiple devices
- Live data sharing during demonstrations. Great for in-person and remote learning
- Graph types, including bar graphs, histograms, and FFTs, plus the ability to plot categorical data
- Video-sensor data sync to replay, speed up, slow down, and pause recorded experiments at key moments in time
- Library of over 45 sample experiments ready to be analyzed by students as prep work, homework, or a makeup assignment
- User-defined curve fits, which allow advanced and more meaningful data analysis
Rechargeable Battery
The robust rechargeable battery offers long battery life and provides always-ready operation when using the sensor wirelessly. Monitor battery life directly from the Vernier Graphical Analysis™ Pro app, as well as LabQuest®3. Should the battery run low, simply connect the sensor to the charging cable and keep on collecting - no interruptions or inconvenience to you or your students.
Wireless or Wired
Go Direct sensors connect directly to your mobile device, Chromebook™, or computer using the Vernier Graphical Analysis™ Pro app - no additional equipment or software purchases are necessary. Go Direct sensors can be used wired via USB or wirelessly via Bluetooth® wireless technology, allowing you to choose the solution best for your classroom or laboratory.
Specifications
- Range: 0 to 400 kPa
- Resolution: 0.03 kPa
- Accuracy: ±3 kPA
- Maximum sampling rate: 50 samples/s
- Internal volume: 0.8 mL
- Maximum pressure that the sensor can tolerate without permanent damage: 450 kPa
- Connections:
- Wireless: Bluetooth
- Wired: USB
What's Included
- Vernier Go Direct Gas Pressure Sensor
- Tapered valve connectors (2) inserted into a No. 5 stopper
- Tapered valve connector (1) inserted into a No. 1 stopper
- Two-way valve
- 18 inch Tygon tubing with Luer Lock connectors
- 20 mL syringe
- White transpiration tubing clamps (2)
